BrewBuilt™ IceMaster Max 2 Glycol Chiller
GLY357

BrewBuilt™ IceMaster Max 2 Glycol Chiller

In Stock
Returns
60 day no hassle return policy. Details
Description

The IceMaster Max 2 is designed to cool fermentations in small vessels. It features 2 built-in submersible pumps with independent digital temperature controllers and can be used with any vessel that has a glycol jacket or submersed cooling coil/rod. Each controller includes a temperature probe that should be inserted into a thermowell in your vessel or can be taped to the outside of the vessel if you don't have a thermowell. The digital controller then measures the temperature of your tank and turns the submersible pump on or off to cool to your desired set temperature. Up to two tanks can be controlled separately with one IceMaster Max 2.

The Max 2 is the perfect unit for brewers with 1 or 2 fermentation vessels. The IceMaster 100 and IceMaster Max 4 are terrific chillers, but for they have far more cooling capacity than the average homebrewer needs. The Max 2 is the most affordable glycol chiller we offer, and thanks to the built-in submersible pumps and controllers, there's no need to purchase additional pump kits to use with your cooling system(s).

Compatibility
The IceMaster can be used with any fermenter that has a built-in cooling jacket, added CoolStix, or a submersed cooling coil. It works well as the cooling source for the following sytems and fermenters.

  • CoolStix - CoolStix can be added to a wide range of carboys, fermenters, and tanks and the IceMaster works really well in combination. Each CoolStix is available with or without a pump kit; for use with the IceMaster Max 2 you will only need the CoolStix and some tubing to connect it to the chiller.
  • Ss Brewtech Fermenters and Brites - Ss BME Chronicals, BME Brites, and Unitanks come with cooling coils and neoprene as standard. The optional chilling FTSs will not be needed for use with the Max 2.
  • Spike Conical with Optional Cooling Coil - the cooling coil for Spike CF series conicals is available for purchase independently from the TC-100 cooling system. For use with the Max 2 you will only need the the coil and some tubing to connect it to the chiller.
  • Speidel Tanks with Optional Cooling Jackets - You will need two lengths of tubing to connect the chiller to each tank.
  • Grainfather Fermenters - Grainfather fermenters have standard cooling jackets. You will need two lengths of tubing for each fermenter.
  • Blichmann Fermenators with Optional Cooling Coil - You will need two lengths of tubing for each Fermenator.

Capacity
It is always difficult to determine exactly how many tanks can be chilled at one time as it depends on what is happening in each tank, if the tank is insulated, and what the ambient temperature is. Cold crashing always requires the most energy and requires tank insulation. We have experimented with capacities and can provide this general guide based on a 75°F ambient and neoprene insulation. Neoprene provides a modest amount of insulation so you would obtain better results using Armaflex or a higher R rated insulation.

At 75°F ambient temperature with neoprene insulation, the Max 2 can cold crash one 1 BBL tank or two tanks up to 15 gallons in size at one time.

Set Up
In order to hook up the IceMaster to your fermenter or tank's cooling system, you will need 2 lengths of tubing per vessel. All tubing connections should be secured with hose clamps.

  • Length 1: Barb of 1st bulkhead (IN) to cooling system outlet
  • Length 2: Barb of 2nd bulkhead (OUT) to cooling system inlet

Specifications:

  • 2 built-in submersible pumps with independent digital controllers
  • Pump controllers reads in °F or °C
  • Temperature controller reads in °C
  • Labeled IN and OUT stainless bulkheads with 3/8" OD barbs
  • Tank Capacity: 17 L / 4.5 Gal. Water Capacity
  • Compressor: 3/8 HP
  • Cooling Capacity: 600 Watt/2000btu/.17 tons
  • Refrigerant: r134a
  • Voltage: 110V
  • Dimensions: 19" x 12" x 17.5"
  • Wheels not included




Item # GLY357
Shipping Eligible for Free Shipping Program
Availability California - In Stock
Pennsylvania - Out Of Stock
Weight 50 LBS
Documents

Community Q&A

Start typing your question and we'll check if it was already asked and answered. Learn More
Browse 7 questions Browse 7 questions and 11 answers
Why did you choose this?
MoreFlavor Store
The price is the greatest incentive for this chiller. Also having the pumps and temperature controllers included is a huge savings. I plan on using this unit with SS Brewtech Chronicals, and it is a seamless match.
Mark D on Aug 2, 2020
Because I need to chill.... a couple of conicals...
Justin V on Aug 2, 2020
The price is the greatest incentive for this chiller. Also having the pumps and temperature controllers included is a huge savings. I plan on using this unit with SS Brewtech Chronicals, and it is a seamless match.
Mark D on Aug 2, 2020
Good price, good reviews. Meets the needs.
John M on Aug 2, 2020
Because I need to chill.... a couple of conicals...
Justin V on Aug 2, 2020
Internal pumps with dual controllers
Dana B C on Aug 2, 2020
Good price, good reviews. Meets the needs.
John M on Aug 2, 2020
Internal pumps with dual controllers
Dana B C on Aug 2, 2020
What is the decibel rating for this unit under load? Is is louder than a typical mini-fridge?
Jason Amsden on May 3, 2020
Are there going to be wheels available for this?
brian romanowski on Apr 16, 2020
BEST ANSWER: At this time we do not have plans to add caster options for this unit. I will pass your question along to our development team so they can get started on it. Cheers!
Can this be used with immersion chiller to cool wort after boil?
Mark Ingham on Mar 20, 2020
BEST ANSWER: We do not recommend using this to chill hot wort. The liquid coming out of your heat exchanger will be too hot for the compressor to handle and will burn out the machine quickly. We can recommend using the glycol to cool down a tank or bucket full of water that you can recirculate through your wort chiller. This will stop the chiller from being overwhelmed and will still save you water along the way.
Can this unit present Fahrenheit values?
Jason Amsden on May 3, 2020
BEST ANSWER: Yes it can be switched from Celsius to Fahrenheit in the controllers' digital menus.
Will this work with the SS Brewtech Brew Buckets?
Anthony on Apr 2, 2020
BEST ANSWER: Yes. This glycol chiller will work with any fermenter that has an internal chilling coil or a jacket.
Will this chiller allow me to Lager a brew in my SS Brewtech conical with FTS lid?
Thomas S on Jul 1, 2020
BEST ANSWER: Hi Tom - the cooling capacity is greatly dependent on the ambient temperature, volume of the fermentation, and whether the fermenter is insulated with neoprene or other material. With that in mind, at 75°F ambient temperature with neoprene insulation, the Max 2 can cold crash one 1 BBL tank, so it should be fine maintaining lagering temperatures for your conical, assuming it's below 1 BBL in size.
Reviews

There are no reviews for this item. Write Review
