Duotight Push-In Fitting - 8 mm (5/16 in.) x Female Beer Thread
DUO104

Duotight Push-In Fitting - 8 mm (5/16 in.) x Female Beer Thread

In Stock
Delivers to ( change ) by as part of our Fast & Free Shipping.
Faster Shipping Available. Details.
Returns
60 day no hassle return policy. Details
Description

This Duotight to Female Beer Thread (5/8" BSP) fitting can be used to connect beverage line to faucet shanks instead of a tailpiece, and it's also a convenient option for connecting gas and beverage line to the gas in and bev out on keg couplers. Compatible with EVABarrier 8 mm OD Tubing (D1717 & D1718).

Duotight fittings are high-quality push-in fittings that seal tight and offer superior sealing capacity due to the double O-ring sealing design.

High Performance Double O-Ring Design:
The secret to Duotight’s superior sealing performance comes from the fact that they use not one, but two high-quality EPDM O-rings.  The double O-ring means they have literally twice the sealing surface when compared with other push-in fittings.  This makes them more reliable and significantly reduces the chance of leakage.

The double O-ring system also means that tubing can be bent at a much tighter radius without causing leaking issues, which can be an issue with other fittings.  This combination of factors makes Duotight the most reliable push-in fittings on the market.

EPDM offers excellent chemical resistance for a longer life span. When compared with silicone and vinyl, EPDM has much better gas transmission rates, better wear resistance, and is BPA-free.

No Clamps Necessary!
We recommend cutting your tubing straight, not on an angle, to ensure the line forms a complete seal. To remove the fitting simply push in the collet and the hose can be removed.

Features:

  • Insert tubing and firmly push to connect
  • Easily release tubing by pushing in the collet
  • Suitable for both gas & beverage applications
  • Made from food-grade acetal plastic
  • Double O-rings made from highly chemical resistant EPDM
  • Locking teeth made from stainless steel
  • Pressure rated to 150 psi

Temperature rated to 212°F (100°C)Please note: exposure to chlorine will degrade the acetal plastic and stainless steel these fittings are made from. Do not use in contact with bleach or other chlorinated cleaning chemicals.

Faucet shank and keg coupler not included.

Kegland Part number: KL06903



Item # DUO104
Shipping Eligible for Free Shipping Program
Availability In Stock
Weight 0.05 LBS
Community Q&A

Start typing your question and we'll check if it was already asked and answered. Learn More
Browse 8 questions Browse 8 questions and 16 answers
Why did you choose this?
MoreFlavor Store
These work great
Michael R on Mar 3, 2023
recommendation
Michael O on Jan 31, 2023
These work great
Michael R on Mar 3, 2023
Change sanke tap beer line to barrier
Jason W on Feb 21, 2023
recommendation
Michael O on Jan 31, 2023
Converting from.crimp on fittings to push in fittings.
Carl S on Dec 2, 2022
gift request
Cassie G B on Dec 1, 2022
I want to go from a camlock to tubing
Kerley Engineering G on Nov 15, 2022
required
michael h on Sep 23, 2022
Others work
Nicholas J L on Sep 9, 2022
Aligned with my design of my keezer
Albert L on Aug 24, 2022
EVABarrier and DuoTight is the best system for lines
Clifford W on Aug 23, 2022
Easy fit
Cesar M on Aug 18, 2022
east coupler connects
George R on Aug 17, 2022
the best
Steven B on Aug 11, 2022
To occasionally use with commercial keg and to use with hand pump cleaning system.
James D on Aug 5, 2022
I like spending money
Eric Y. on Jul 23, 2022
Fittings for my coupler and easy use
Anthony F on Jul 23, 2022
Complete my Jockey Box build.
Eddie M on Jul 15, 2022
replacing all my beer and gas lines
Matt L on Jun 21, 2022
rebuilding my kegerator and a friend uses this and is very happy.
Scott on Jun 20, 2022
seems solid
Lilly Romo D on May 25, 2022
Duotight is the most convenient beer/gas line system out there
Mark W on May 3, 2022
Easy install
Scott T on Apr 28, 2022
improving my system
Mark L on Apr 22, 2022
Complete rebuild of gas side in my Kegerator.
Trevor W on Apr 6, 2022
To avoid a barb
Miles J on Apr 2, 2022
More beer
Matthew B on Mar 30, 2022
Ease of use and assembly
Upgrading gas lines, making a keezer
Preston G on Mar 16, 2022
converting a used kegerator to new/modern beer lines these will go on the D style coupler.
David J on Mar 10, 2022
Replace my close clearance kegerator
RANDALL B on Mar 5, 2022
With a flare adapter on the top of the sankey D type coupler, adding the duotight to flare adapter was too tall and this solves the issue with a single adapter to the keg connector.
Dean on Mar 5, 2022
I want to convert my keg to Duotight
Jesse A on Mar 4, 2022
Have used these for a while - love them. As I'm replacing everything now that I'm gluten free, I'm ordering another set.
Mike F on Feb 24, 2022
Replacing and upgrading kegerator liquid lines
Trevor G F on Feb 10, 2022
Counter pressure filling from brite tank
Peter F on Jan 25, 2022
To fit D Coupler
Edward P on Jan 22, 2022
Using on the tap shafts to connect my tap cooler.
Scott on Jan 7, 2022
need to setup a longer line in my kegerator
Mike R on Jan 5, 2022
Christmas Gift
Joshua David M on Dec 8, 2021
Easier than fooling with the barbs
david k on Dec 8, 2021
To upgrade to a superior oxygen mitigating tubing for dispensing.
Kevin H on Dec 4, 2021
brulosophy told me to
Jonathan D on Oct 21, 2021
game changer
Timothy G on Oct 18, 2021
rebuilding draught innards after moving and sitting for a long time.,
Mark W on Oct 8, 2021
So much easier to manage than clamps.
Christian A on Jul 8, 2021
If you're not already using duotight, you're making things way harder on yourself then it needs to be.
Matthew B on Jul 2, 2021
Trying out quick connect
Russell Bonsall on Jun 29, 2021
Quick line changes
Gregory J K on Jun 28, 2021
Upgrading beer lines.
Carl S on Jun 9, 2021
the best
Miguel U on Jun 2, 2021
Change sanke tap beer line to barrier
Jason W on Feb 21, 2023
Converting from.crimp on fittings to push in fittings.
Carl S on Dec 2, 2022
Can this be used with a 2" shank in a draft tower? The current shanks are the Intertap ones with permanent 90 degree barbs and I am hoping to convert entirely to the Duotight fittings.
Adam E on Jul 25, 2019
Duotight Push-In Fitting - 8 mm (5/16 in.) x Female Beer Thread
Duotight Push-In Fitting - 8 mm (5/16 in.) x Female Beer Thread
Beer Faucet Shank | Tower Shank | Stainless | Intertap® | NukaTap®
Beer Faucet Shank | Tower Shank | Stainless | Intertap® | NukaTap®
Beer Faucet Shank | Stainless | 2 in. | Includes 3/16
Beer Faucet Shank | Stainless | 2 in. | Includes 3/16" nipple back nut and plastic collar
BEST ANSWER: The threads on the 2'' shank are 5/8'' BSP threads so the DUO104 unfortunately will not be compatible. However, we will be offering the short tower shanks that have Duotight compatible barbs very soon!
i have this tubing, will it fit with this? Accuflex Bev-Seal Ultra beer line. 3/16' ID
Tom H on Mar 27, 2020
BEST ANSWER: I am personally unfamiliar with the tubing you’re going to use. If the OD is 5/16” and you have a straight cut, push your tubing in until it totally stops. Run a leak test using water. If you need to remove the tubing, the Duotight fitting will release with pressure applied to the circular collar where the tubing is inserted and a firm pull on the tubing. If the duotight fitting on your particular tubing leaks, I recommend what I use and got on on this website, EVABarrier 8mm tubing, D1717 or D1718.
Would this work with a welded shank?
Guillermo V on Aug 8, 2023
Duotight Push-In Fitting - 8 mm (5/16 in.) x Female Beer Thread
Duotight Push-In Fitting - 8 mm (5/16 in.) x Female Beer Thread
Beer Faucet Shank | 2.5 in. | Welded 3/16
Beer Faucet Shank | 2.5 in. | Welded 3/16" barb | Includes plastic collar
I want to use these in my keezer build. what size shanks should I buy to go through 2x4 leaving enough room to connect these?
John F on May 12, 2020
BEST ANSWER: If you are going through the 2" side of the board then you will be fine with using the 3.5 or 4 inch shank. There will be plenty of space for the lock nut and the tube fitting.
Will this duotight fitting fit this shank? https://www.morebeer.com/products/beer-faucet-shank-5.html Also, do you know when this will be back in stock?
Adam L on Jun 25, 2020
BEST ANSWER: This is the correct duotight fitting for beer shanks as well as sanke keg couplers commonly referred to as "Beer Thread".
Will this work with my D1244A Beer Faucet Shank? Would be my answer since EVA tubing will not work with the tail piece barb.
Thomas C on Feb 7, 2023
Duotight Push-In Fitting - 8 mm (5/16 in.) x Female Beer Thread
Duotight Push-In Fitting - 8 mm (5/16 in.) x Female Beer Thread
Beer Faucet Shank (Stainless) - 3 in.
Beer Faucet Shank (Stainless) - 3 in.
BEST ANSWER: Absolutely! That's the part. Part number DUO104. Cheers!
Does this fitting work with welded barb shanks? https://www.morebeer.com/products/komos-beer-faucet-shank-312-nipple.html
Guillermo V on Jul 9, 2023
BEST ANSWER: No, it will not.
Will the female beer thread Duotight fit a u system, Guinness coupler or only the Sankey coupler?
PATRICK L F on May 4, 2022
BEST ANSWER: Yes. The threading on this will fit all styles of Sanke coupler.
Reviews

4.5 / 5.0
24 Reviews
5 Stars
4 Stars
3 Stars
2 Stars
1 Star
20
0
1
1
2
Rated 2 out of 5
They leak, even with an elbow to reduce tension
I bought a few of these princesses with the intention of slowly converting my keezer from barbed tailpieces with the Evabarrier stretched over them + Oetiker clamp, to all duotight. Big mistake. Any amount of leakage is not okay, because a steady drip will put your precious beer on your keezer and floor.
What I'm noticing is that any kind of bend or deflection in the line will unseat the fitting (for example if you are adding a keg in, and have to move the lines for a moment), it will range from drip to spray. They just don't form a quality seat.
The worst part is if you make a mistake, or want to try re-seating, good luck getting the evabarrier out of there. I even bought the special tools to remove them, and the little clip-locks. I've wasted like $50 on these fittings. I'm going back to barbs and Oetiker clamps.
I only gave this two stars in the event you have a perfectly plumbed set of lines that can punch straight in and never see any deflection. If princess always gets her way, she probably works just fine.
February 23, 2024
Purchased
over 5 years ago
Rated 5 out of 5
Duotight
The duotight fitting work great I am changing all my keezer lines over with no problems
April 4, 2023
Purchased
1 year ago
Rated 1 out of 5
Not usful for me
Was hoping to be able to change between my corny kegs and Sanke kegs. On my previous kegerator I had put FFL fittings on the beer lines and had MFL ball locks as well as MFL 5/16th fitting so I could easily switch between homebrew and commercial kegs. These fittings do not allow you to do so.
December 17, 2022
Purchased
over 2 years ago
Rated 5 out of 5
Duotight Push-In Fitting - 8 mm (5/16 in.) x Female Beer Thread
Worked the first time and everytime.
August 30, 2022
Purchased
over 2 years ago
Rated 5 out of 5
Does what it looks like very well
This thing is perfect for the use case - a simplified DuoTight connection at the end of a tap shank or on a Sankey keg (I think, haven't tried that but the threading should be the same).
July 31, 2022
Purchased
over 4 years ago
Rated 5 out of 5
It fit the coupler perfectly !!
March 23, 2022
Purchased
over 2 years ago
Rated 5 out of 5
DuoTight Connectors
The DuoTight fittings are the way to go, but with the myriad of sizes for hoses and fittings, regulator barb fittings, keg line requirements for compessation of PSI, metric vs standard, and other connector requirements, it can be really confusing, and over buying will result. It would be nice if there were some standard guide how to employ these fittings, but I am glad with the purchase, nonetheless.
July 2, 2021
Purchased
over 3 years ago
Rated 5 out of 5
Works as promised
I upgraded to these and love how simple they are to use.
Just make sure you cut the tube going in very square. My first cut has a little bit on an angle and it leaked. I squared it up and it's been perfect.
June 24, 2021
Purchased
over 3 years ago
Rated 5 out of 5
Duotight Push-In Fitting - 8 mm (5/16 in.) x Female Beer Thread
No complaints..does what its supposed to do
June 10, 2021
Purchased
over 5 years ago
Rated 3 out of 5
I like them, but they are sensitive
First off, I love the ease of the Duotight connectors for changing couplers/disconnects if you switch between commercial kegs and ball lock kegs. What I don't like is how easy it is to over-tighten the fittings and cause a hairline crack that eventually leaks gas - whether right away or after some time/pressure.
June 9, 2021
Purchased
